High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop

China Guangzhou Kinte Electric Industrial Co.,Ltd certification
China Guangzhou Kinte Electric Industrial Co.,Ltd certification
They have supplied us one full assembly line for our freezer production.We strongly recommend them for such jobs at your godrej plants.

—— Harmeet Singh

I'm Online Chat Now

High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop

High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop
High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop

Large Image :  High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: Kinte
Certification: Certificate of conformity of quality management system certification
Model Number: customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Customized
Packaging Details: Customized
Delivery Time: Customized
Payment Terms: TT,L/C
Supply Ability: Customized
Detailed Product Description
High Light:

industrial automation Robot

,

assembly line robot

High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop



Quick Detail:



Place of Origin Guangdong, China (Mainland)

Brand Name CEI KINTE

Condition New

After-sales Service Provided Engineers available to service machinery overseas

name 6 axis robot



The robot used in sheet-metal workshop mainly have two type:DF-5045-S1 and DF-5045-S2

  1. All the business of Kinte is international and abroad only.

      2.We have a large team and we provide one-station service

  1. We provide one-station service
  2. What you need is a thought then we make it come true.
  3. We have a big team,we are always ready to go for installation and maintenance and training.
  4. We have many abroad experience.



Description:



6 axis robot



We have all kinds of robot which can help you achieve robotization,and we have lots of video of robot ,contact me freely if you have any interested.



Specifications:



Model

DF-5045-S1

DF-5045-S2

Power

220V±10%,50Hz

220V±10%,50Hz

Rated power

0.5KW/H

0.8KW/H

Working environment

Temperature:0-45℃  Humidity:45%-65%

Temperature:0-45℃  Humidity:45%-65%

Swinging angle

180º

180º

Working stroke

For moving up and down 500mm,  for moving front and aid 400mm(adjustable)

For moving up and down 500mm,  for moving front and aid 700mm(adjustable)

Beam rotation Angle

360º

360º

Fetch the chuck rotation Angle

360º

360º

Production efficiency (depend on the size of product)

400—800pcs/H

400—800pcs/H

Material supplying precision

±0.2

±0.2

Working radius

1100mm-1500mm

1500mm-2200mm

Sucking weight

Less than 3kg

Less than 13kg

Machine size(L*W*H)

920*600*1750

920*600*1750

Weight

About 200kg

About 400kg

Competitive Advantage:



  1. Five-axis linkage technology at a high speed This series Robot adopt Five-axis linkage technology

at a high speed and we have the independent patent technology.The operation efficiency can obtain

8-12times/min,which is in the international advanced level.



    2. Precise positioning technology

This series Robot adopt positive and negative gear back gap buffer which is search and developed independently.it is equipped on the planetary gear reducer,the positioning error value is control within + / - 0.2 mm,this can get the international advanced level.



High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop 0

Suitable for DF-5045-S1 robot small and medium-sized hardware examples



3. Intelligent motion control technology

Adopt intelligent motion control card,perform the arc motion curve;it can identify the double material;Intelligent identification punch stamping twice or more,which can protect the security of robot and punching machine;the storage can obtain 100units product information.

4. Vacuum stable adsorption technology

Adopt inner vacuum compressor manner,providing a independent,stable air source for the vacuum absorption of robot tongs.This can making the use of the robot not affected by the air source of the ground,it can also guarantee the safety and stability of the tongs vacuum scratch,which can avoid the workpieces’ falling down in the way.



High Speed Industrial Robot 6 Axis Robot For Sheet-Metal Workshop 1

suitable for DF-5045-S2 middle and largest hardware samples



5. Core parts

This series robot is adopted PLC,servo,motor,vacuum pump etc all come from Omron or Taida,Japan morita,America AIRTECH, lead screw,straight guide rail,air cylinder etc is MISUMI,HIWIN, Airtac etc international brand.



6 axis robot

CEI robot is mainly used for material handling, it is a good way to replace man power from some dangerous work
